Pro-Mod Series
Loaded with premium features, this Pro-Mod Plus Dinky® DK24 2PT model features a sleek Dinky® body constructed from basswood, sculpted shredder's cut heel and scalloped lower back bout for seamless access to the upper registers. The bolt-on caramelized maple neck features graphite reinforcement for rock-solid stability, a satin natural finish on the back of the neck for sublime playability, and a conveniently located heel-mount truss rod adjustment wheel for neck relief tweaks on the fly. Designed for speed, the 12"-16" compound radius ebony fingerboard features comfortable rolled edges, 24 stainless steel jumbo frets and Luminlay® side-dots for enhanced visibility in low-light conditions.
This axe features an HH pickup configuration consisting of a direct mount Seymour Duncan® Full Shred™ TB-10 bridge pickup and direct mount Seymour Duncan® Alnico Pro II™ APH-1N neck pickup. The bridge pickup radiates a crisp top-end with low-end articulation, while the neck pickup has incredible range with soaring highs and silky lows.
Other premium modern features include a five-way blade pickup switch, speed knobs for the volume and no-load tone controls, Wilkinson® recessed tremolo bridge with locking saddles, Charvel-branded die-cast locking tuners and more.
Blending sophisticated style with assertive tone, the Pro-Mod Plus Dinky® DK24 2PT HH E delivers premium performance and modern features.
-
Specs
General
Model Number 2972811576 Series Pro-Mod Plus Color Celestial Silk Number of Strings 6 Orientation Right-Hand Electronics
Bridge Pickup Seymour Duncan® Full Shred™ TB-10 Neck Pickup Seymour Duncan® Alnico II Pro™ APH-1N Pickup Color Parchment Controls Volume (500K EVH® Bourns® Low Friction Pot), No-Load Tone Pickup Switching 5-Position Blade: Position 1. Bridge Pickup, Position 2. Both Outer Coils, Position 3. Bridge and Neck Pickup, Position 4. Both Inside Coils, Position 5. Neck Pickup Auxiliary Switching 2-Position Mini Toggle Down/All Series, Up/All Parallel Pickup Configuration HH Hardware
Bridge Wilkinson® WVS130-2P Tremolo Hardware Finish Chrome Tremolo Arm Wilkinson® Tuning Machines Charvel®-Branded Die-Cast Locking Pickguard None Control Knobs Speed Knob Switch Tip Parchment Neck
Neck Material Caramelized Maple Neck Construction Bolt-On with Graphite Reinforcement Neck Finish Natural Satin Neck Shape Speed Neck with Rolled Fingerboard Edges Neck Binding None - Rolled Fingerboard Edges Scale Length 25.5" (648 mm) Fingerboard Radius 12"-16" Compound Radius (304.8 mm to 406.4 mm) Fingerboard Material Ebony Number of Frets 24 Fret Size Jumbo Stainless Steel Nut Material Graph Tech TUSQ XL Nut Width 1.6875" (42.86 mm) Position Inlays 4mm Pearloid Dot Side Dots Luminlay® Truss Rod Nut Heel-Mount Truss Rod Adjustment Wheel String Trees Fender® Standard String Guide Headstock Licensed Fender® Stratocaster® Neck Plate None - 4-Bolt Sculpted Heel Miscellaneous
Strings Nickel Plated Steel (.009-.042 Gauges) Strap Buttons Standard Case/Gig Bag Included Charvel® Deluxe Gig Bag (P/N 7729019000) Other Features Luminlay® Side Dots - Gallery
