Pro-Mod Series
Loaded with premium features, this Pro-Mod Plus Dinky® DK24 2PT HSS E QM model features a sleek Dinky® body constructed from basswood with a quilt maple top, sculpted shredder’s cut heel and scalloped lower back bout for seamless access to the upper registers. The bolt-on caramelized maple neck features graphite reinforcement for rock-solid stability, a satin natural finish on the back of the neck for sublime playability, and a conveniently located heel-mount truss rod adjustment wheel for neck relief tweaks on the fly. Designed for speed, the 12”-16” compound radius ebony fingerboard features comfortable rolled edges, 24 stainless steel jumbo frets and Luminlay® side-dots for enhanced visibility in low-light conditions.
This axe features an HSS pickup configuration consisting of a direct mount Seymour Duncan® Full Shred™ TB-10 bridge pickup and direct mount Seymour Duncan® Custom Flat Strat® SSL-6 single-coil middle pickup and Seymour Duncan Custom Flat Strat SSL-6 RWRP single-coil neck pickup ith plenty of focused humbucker grit and springy vintage snap.
Other premium modern features include a five-way blade pickup switch, speed knobs for the volume and no-load tone controls, Wilkinson® recessed tremolo bridge with locking saddles, Charvel-branded die-cast locking tuners and more.
Blending sophisticated style with assertive tone, the Pro-Mod Plus Dinky® DK24 2PT HSS E QM delivers premium performance and modern features.
-
Specs
General
Model Number 2972813546 Series Pro-Mod Plus Color Blue Curaçao Number of Strings 6 Orientation Right-Hand Electronics
Bridge Pickup Seymour Duncan® Full Shred™ TB-10 Middle Pickup Seymour Duncan® Custom Flat Strat® SSL-6 Single-Coil Neck Pickup Seymour Duncan® Custom Flat Strat® SSL-6 RWRP Single-Coil Pickup Color Black/Cream Controls Volume (500K EVH® Bourns® Low Friction Pot), No-Load Tone Pickup Switching 5-Position Blade: Position 1. Full Bridge Pickup, Position 2. Bridge Inner Coil and Middle Pickup, Position 3. Bridge Outer Coil and Neck Pickup, Position 4. Middle and Neck Pickup, Position 5. Full Neck Pickup Pickup Configuration HSS Body
Body Finish Gloss Body Shape Dinky® Body Material Basswood Body Top Quilt Maple Hardware
Bridge Wilkinson® WVS130-2P Tremolo Hardware Finish Chrome Tremolo Arm Wilkinson® Tuning Machines Charvel®-Branded Die-Cast Locking Pickguard None Control Knobs Speed Knob Switch Tip Black Neck
Neck Material Caramelized Maple Neck Construction Bolt-On with Graphite Reinforcement Neck Finish Natural Satin Neck Shape Speed Neck with Rolled Fingerboard Edges Neck Binding None - Rolled Fingerboard Edges Scale Length 25.5" (648 mm) Fingerboard Radius 12"-16" Compound Radius (304.8 mm to 406.4 mm) Fingerboard Material Ebony Number of Frets 24 Fret Size Jumbo Stainless Steel Nut Material Graph Tech TUSQ XL Nut Width 1.6875" (42.86 mm) Position Inlays 4mm Pearloid Dot Side Dots Luminlay® Truss Rod Nut Heel-Mount Truss Rod Adjustment Wheel String Trees Fender® Standard String Guide Headstock Licensed Fender® Stratocaster® Neck Plate None - 4-Bolt Sculpted Heel Miscellaneous
Strings Nickel Plated Steel (.009-.042 Gauges) Strap Buttons Standard Case/Gig Bag Included Charvel® Deluxe Gig Bag (P/N 7729019000) Other Features Luminlay® Side Dots -
